HRP-580 Gun Laser Methane Detector
Remote Portable CH₄ Leak Detection Solution Based on TDLAS Technology
Product Introduction
HRP-580 gun laser methane detector is a professional portable methane (CH) leakage detection equipment, which is specially designed for fast, accurate and safe gas detection applications. The equipment adopts advanced tunable semiconductor laser absorption spectroscopy (TDLAS), which can realize non-contact methane detection under long-distance conditions, and help operators to quickly find gas leakage without going near dangerous areas.
HRP-580 has a maximum detection distance of 200m and a detection range of 0 ~ 100,000 ppm·m, and is widely used in natural gas pipelines, oil and gas facilities, chemical plants, gas stations and industrial safety detection.
The product adopts ergonomic gun-type portable design, which is simple to operate and convenient to carry. At the same time, it has Ex ib IIC T4 Gb explosion-proof certification, IP65 protection level, Bluetooth data transmission, acousto-optic alarm and rechargeable lithium battery, which can meet the long-term stable operation requirements in complex industrial environment.
Principle of Operation
HRP-580 adopts advanced TDLAS (tunable semiconductor laser absorption spectrum) technology to detect methane.
The equipment irradiates the target area by emitting infrared laser with a specific wavelength. When methane molecules exist in the detection path, methane will absorb the laser energy with the corresponding wavelength. The device calculates the methane concentration in the detection path by analyzing the change between the emitted light and the received light and combining with the internal algorithm.
Different from the traditional contact gas detector, HRP-580 can complete the detection without contacting the leakage source, and realize remote and non-contact gas leakage detection, which effectively improves the detection efficiency and reduces the safety risk of workers entering dangerous areas.
Detection Process:
- The laser module emits infrared laser with a specific wavelength;
- Methane molecules absorb laser energy of corresponding wavelength;
- The optical sensor receives the changed laser signal;
- Internal algorithm to calculate methane concentration;
- Display the test results, and start the alarm when it exceeds the standard.
Product Advantage
1. Remote Non-Contact Detection
HRP-580 supports long-distance detection of up to 200 meters, and workers can check the leakage of pipelines, valves, storage tanks and industrial equipment in a safe place.
Advantages:
- Reduce the risk of personnel entering dangerous areas;
- Improve inspection efficiency;
- It is suitable for the inspection of large industrial facilities.
2. High-Precision TDLAS Laser Detection Technology
Advanced TDLAS laser detection technology is adopted, which has excellent methane selectivity and fast response ability.
Main Features:
- Accurately identify methane gas;
- Strong ability to resist environmental interference;
- Response time ≤0.1 second;
- Provide reliable leak detection results.
3. Wide Range of Methane Detection Capability
Detection range of HRP-580:
0～100000 ppm·m
It can not only detect tiny methane leakage, but also identify high concentration leakage areas to meet the detection requirements of different industrial scenarios.
4. Explosion-Proof Industrial Design
Designed for hazardous industrial environment, HRP-580 has:
- Explosion-proof grade: Ex ib IIC T4 Gb
- Protection grade: IP65
Can be stably applied to:
- Oil field;
- Natural gas station;
- Chemical production area;
- Flammable and explosive industrial environment.
5. Portable Gun Design
The gun structure conforms to ergonomic design, which is convenient for workers to quickly locate and detect leakage points.
Product Features:
- Light weight and easy to carry;
- It can be operated with one hand;
- Quickly complete the inspection task;
- Suitable for mobile safety inspection.
6. Bluetooth APP Data Management
The device has a built-in Bluetooth communication function, which can be connected with a special APP to realize the management of detection data.
Support:
- Check the detection data in real time;
- Save inspection records;
- Data transmission management;
- Improve the efficiency of safety management.
7. Long Battery Life Design
Powered by rechargeable lithium battery:
- Working hours ≥8 hours;
- Support long-term on-site inspection;
- Convenient charging and maintenance.
Application Industry
Oil and Gas Industry
HRP-580 is widely used in:
- Natural gas pipeline;
- Gas station;
- Compressor station;
- Gas storage facilities;
- Pipeline valve area.
It can help workers quickly find the risk of leakage and reduce the risk of fire, explosion and environmental pollution.
Petrochemical Industry
Applicable to:
- Chemical production equipment;
- Gas treatment system;
- Tank area;
- Industrial safety inspection.
Natural Gas Supply System
Apply to:
- Gas filling station;
- Urban gas pipeline network;
- Pressure regulating station;
- Natural gas supply facilities.
Remote detection ability can effectively improve the inspection efficiency.
Industrial Safety Inspection
Applicable to:
- Daily factory inspection;
- Equipment maintenance inspection;
- Emergency investigation of leakage;
- Patrol inspection of dangerous areas.
Mining Industry
Can be used for:
- Mine methane detection;
- Investigation of potential safety hazards;
- Ventilation system inspection.
Technical Parameter
| Parameter | Specification |
|---|---|
| Detecting gas | Methane (CH) |
| Detection principle | TDLAS tunable semiconductor laser absorption spectrum |
| Detection range | 0 ~ 100000 ppm·m |
| Resolution | 1 ppm·m |
| Detection accuracy | ±10% FS |
| Detection distance | 0 ~ 200 m |
| Response time | ≤ 0.1 second |
| Protection grade | IP65 |
| Explosion-proof grade | Ex ib IIC T4 Gb |
| Alarm mode | Acousto-optic alarm |
| Data transmission | Bluetooth APP |
| Power supply | Rechargeable lithium battery |
| Working hours | ≥ 8 hours |
| Weight | 775g |
Frequently Asked Questions (FAQ)
1. What gas does HRP-580 detect?
HRP-580 is specially used to detect methane (CH) gas leakage, which is widely used in natural gas and industrial methane detection scenarios.
2. What detection technology does HRP-580 use?
The equipment adopts advanced TDLAS tunable semiconductor laser absorption spectroscopy technology to realize fast and high-precision non-contact methane detection.
3. What is the maximum detection distance?
The maximum detection distance of HRP-580 can reach 200 meters, and the specific distance will change according to the site environment and detection conditions.
4. Do you need to touch the leakage point when testing?
No need. HRP-580 adopts laser remote detection technology, which can complete the detection without direct contact with the leakage source.
5. Does HRP-580 have explosion-proof function?
Yes, the equipment has Ex ib IIC T4 Gb explosion-proof grade and is suitable for use in dangerous areas.
6. What is the product protection level?
HRP-580 adopts IP65 protection design, which has good dustproof and waterproof ability.
7. What is the response speed?
The response time of the equipment is less than or equal to 0.1 second, and methane leakage can be found quickly.
8. Which industries are suitable for using HRP-580?
Mainly used in:
- Oil and gas industry;
- Chemical industry;
- Gas supply system;
- Mining industry;
- Industrial safety inspection.
9. How is the test data transmitted?
HRP-580 supports Bluetooth wireless transmission, and can be connected to APP to view and manage test data.
10. How long can the battery last?
Using rechargeable lithium battery, the continuous working time is ≥8 hours under normal circumstances.
11. Can natural gas pipeline leak be detected?
Sure. HRP-580 is especially suitable for methane leakage detection in natural gas pipelines, valves and interfaces.
12. Is it suitable for outdoor use?
Fit. IP65 protection level and industrial design enable it to meet the needs of outdoor inspection.
13. What is the detection accuracy?
The detection accuracy of HRP-580 reaches ±10% FS, which can provide stable and reliable detection data.
14. What is the weight of the product?
The weight of the equipment is about 775g, which is convenient for long-term hand-held inspection.
15. Does HIREP provide OEM customization services?
Yes, HIREP can provide OEM, ODM and customized gas detection solutions according to customer needs.
HRP-580 laser methane detector provides safer, more efficient and more reliable methane leakage detection solutions for oil and gas, chemical industry, industrial safety and other fields with the advantages of long-distance detection, TDLAS laser technology, explosion-proof design and portable operation.
HRP-580 Gun-Type Laser Telemetry Meter
- Detection Gas: Methane (CH₄)
- Detection Principle: Tunable Diode Laser Absorption Spectroscopy (TDLAS)
- Detection Range: 0–100,000 ppm·m
- Resolution: 1 ppm·m
- Detection Accuracy: ±10% FS
- Detection Distance: 0–200 m
- Response Time: 0.1 s
- Operating Temperature: -20℃ to 55℃
- Operating Humidity: 0–95% RH
- Protection Rating: IP65
- Explosion-Proof Rating: Ex ib IIC T4 Gb
- Data Transmission: Bluetooth, compatible with dedicated detection APP
- Alarm Mode: Sound and light alarm
- Laser Safety Class: Infrared detection laser: Class 1; Green indicator laser: Class 3R
- Power Supply: Rechargeable lithium battery
- Operating Time: ≥8 hours
- Instrument Dimensions: 216 mm × 170 mm × 75 mm (L × W × H)
- Instrument Weight: 775 g
Usb cable(Standard):
This Micro USB cable features thickened copper cores and high-density nylon braiding, offering excellent resistance to bending and abrasion for long-lasting durability.
Portable Calibrator Calibration Gas Cylinder(Optional):
The high-precision standard gas supply device designed by portable gas detector is used for periodic calibration, zero correction and range verification of sensors in the field or laboratory to ensure the accuracy and reliability of long-term operation data of testing equipment.
Calibration Hood(Standard):
The compact calibration cover designed by portable hand-held gas detector is used to quickly and accurately complete the zero calibration and range calibration of sensors on the equipment site. It is small, light and precise in structure, which ensures that the standard gas can cover the sensor probe efficiently and avoid the interference of ambient airflow. It is an indispensable professional accessory for daily maintenance and compliance testing.
Air Sampling Probe(Optional):
The high-precision and long-distance gas sampling extension tool designed by portable hand-held gas detector is used to safely and stably extend the probe into narrow space, high place, deep well, pipeline or dangerous area for remote gas detection, which greatly improves the operation safety and detection coverage.Typically used with sampling tubes.
Portable Hand-held Gas Detector Charger(Standard):
The high compatibility, safe and reliable charging solution designed by portable hand-held gas detector includes a standard two-pin plug power adapter and a USB-A to Micro-USB/Type-C data cable (matched according to the equipment interface), which ensures that the equipment can quickly recover power after field inspection, factory duty or emergency tasks, and ensures continuous and stable operation.
Extended Sampling Tube(Optional):
The portable hand-held or pumping gas detector is designed with a high flexibility and corrosion resistance to extend the sampling catheter, which is used to extend the gas inlet of the equipment to the detection points that are difficult to directly contact, such as the depth of the pipeline, the equipment interlayer, the high vent, the inside of the closed container, etc., so as to realize "remote accurate sampling" and greatly improve the detection coverage and operation safety.
Water Vapor and Dust Filter(Optional):
Blocks solid particles from entering the detector's gas path, preventing blockage and avoiding particle adhesion to the sensor surface, which could cause sensor poisoning, decreased sensitivity, slowed response, or even permanent failure. It also avoids physical interference from dust, ensuring the sensor only contacts the measured gas, thus guaranteeing measurement accuracy.
| Name | Chemical Formula | Lower Explosive Limit(Volume Fraction)in Air%VOL|Lower Limit | Serial No | Name | Chemical Formula | Lower Explosive Limit(Volume Fraction)in Air%VOL|Lower Limit | |
| 1 | Ethane | C₂H₆ | 3.0 | 49 | Cyclohexane | CH₂ (CH₂)₄CH₂ | 1.2 |
| 2 | Ethanol | C₂H₅OH | 3.4 | 50 | Cyclohexanol | CH₂ (CH₂)₃CHOHCH₂ | 1.2 |
| 3 | Ethylene | C₂H₄ | 2.8 | 51 | Cyclohexanone | CH₂ (CH₂)₃COCH₂ | 2.8 |
| 4 | Hydrogen | H₂ | 4.0 | 52 | Cyclopropane | CH₂CH₂CH₂ | 2.4 |
| 5 | Methane | CH₄ | 5.0 | 53 | Decane | C₁₀H₁8 | 0.7 |
| 6 | Methanol | CH₃OH | 5.5 | 54 | Cyclohexene | CH₂ (CH₂)₃CHCHCH₂ | 1.2 |
| 7 | Acetylene | C₂H₂ | 2.5 | 55 | Diacetone Alcohol | (CH₃)₂COHCH₂COCH₃ | 1.8 |
| 8 | Propanol | C₃H₇OH | 2.5 | 56 | Di-n-butyl Ether | C₄H₉OC₄H₉ | 0.9 |
| 9 | Propane | C₃H₈ | 2.2 | 57 | Dichlorobenzene | (C₆H₄)Cl₂ | 2.2 |
| 10 | Propylene | C₃H₆ | 2.4 | 58 | Diethylamine | (C₂H₅)₂NH | 1.7 |
| 11 | Toluene | C₆H₅CH₃ | 1.2 | 59 | Dimethylamine | (CH₃)₂NH | 2.8 |
| 12 | Xylene | C₆H₄ (CH₃)₂ | 1.0 | 60 | Dimethylaniline | (CH₃)₂C₆H₃NH₂ | 1.2 |
| 13 | Dichloromethane | C₂H₄Cl₂ | 5.6 | 61 | Dicyclohexylamine | (CH₂)₄O₂ | 1.9 |
| 14 | Dichloroethylene | C₂H₂Cl₂ | 6.5 | 62 | Ethylene Oxide | OCH₂CH₂CH₂ | 1.9 |
| 15 | Dichloropropane | C₃H₆Cl₂ | 3.4 | 63 | Diethyl Ether | C₂H₅OC₂H₅ | 1.8 |
| 16 | Diethyl Ether | C₂H₅OC₂H₅ | 1.7 | 64 | Ethyl Acetate | CH₃COOC₂H₅ | 2.1 |
| 17 | Dimethyl Ether | CH₃OCH₃ | 3.0 | 65 | Ethyl Acrylate | CH₂CHCO₂C₂H₅ | 1.7 |
| 18 | Formaldehyde | CH₂OCH | 4.0 | 66 | Styrene | C₆H₅C₂H₃ | 1.0 |
| 19 | Acetic Acid | CH₃COOH | 4.0 | 67 | Ethylene Oxide | CH₂CH₂O | 2.6 |
| 20 | Acetone | CH₃COCH₃ | 2.3 | 68 | Ethanethiol | C₂H₅SH | 2.3 |
| 21 | Acetyl Chloride | (CH₃CO)₂CH₂ | 1.7 | 69 | Ethyl Mercaptan | C₂H₅SCH₃ | 2.0 |
| 22 | Chloroform | CH₃COCl | 5.0 | 70 | Methyl Ethyl Ketone | C₃H₇COCH₃ | 1.8 |
| 23 | Acrylonitrile | CH₂CHCN | 2.8 | 71 | Ethylamine | C₂H₅NH₂ | 3.5 |
| 24 | Allyl Chloride | CH₂CHCH₂Cl | 3.2 | 72 | Gasoline | — | 0.9 |
| 25 | Methylacetylene | CH₃CCH | 1.7 | 73 | Kerosene | — | 0.7 |
| 26 | Amyl Acetate | CH₃CO₂C₅H₁1 | 1.0 | 74 | Turpentine | — | 1.8 |
| 27 | Aniline | C₆H₅NH₂ | 1.2 | 75 | Nitrobenzene | C₆H₅NO₂ | 1.8 |
| 28 | Benzene | C₆H₆ | 1.2 | 76 | Nitromethane | CH₃NO₂ | 7.1 |
| 29 | Benzaldehyde | C₆H₅CHO | 1.4 | 77 | Phenol | C₆H₅OH | 1.3 |
| 30 | Benzyl Chloride | C₆H₅CH₂Cl | 1.1 | 78 | Phenylacetylene | C₆H₅C₂H | 1.1 |
| 31 | Bromobenzene | C₆H₅CH₂Br | 2.5 | 79 | Ethylbenzene | C₆H₄C₂H₅ | 1.0 |
| 32 | Bromoethane | CH₃CH₂Br | 6.7 | 80 | Methyl Formate | HCOOC₂H₅ | 2.7 |
| 33 | Butadiene | CH₂CHCHCH₂ | 2.0 | 81 | p-Dioxane | C₄H₈O₂ | 2.0 |
| 34 | Butane | C₄H₁0 | 1.9 | 82 | Isobutane | i-C₄H₁0 | 1.8 |
| 35 | Butanol | C₄H₉OH | 1.8 | 83 | Naphthalene | C₁₀H₈ | 1.9 |
| 36 | Butylene | C₄H₈ | 1.6 | 84 | Nonane | CH₃ (CH₂)₇CH₃ | 0.7 |
| 37 | Butyraldehyde | C₃H₇CHO | 1.4 | 85 | Nonanol | CH₃ (CH₂)₇CH₂OH | 0.8 |
| 38 | Butyl Butyrate | C₃H₇COOC₄H₉ | 1.2 | 86 | Valeraldehyde | C₆H₁₀0 | 1.2 |
| 39 | Butyl Methyl Ketone | C₄H₉COCH₃ | 1.2 | 87 | Pentane | C₅H₁2 | 1.4 |
| 40 | Carbon Disulfide | CS₂ | 1.0 | 88 | Pentanol | C₅H₁₁OH | 1.2 |
| 41 | Chlorobenzene | C₆H₅Cl | 1.3 | 89 | Propylamine | C₃H₇NH₂ | 2.0 |
| 42 | Chlorobutane | C₄H₉CH₂Cl | 1.8 | 90 | Propyl Methyl Ketone | C₄H₉COCH₃ | 1.5 |
| 43 | Chloroethane | CH₃CH₂Cl | 3.8 | 91 | Pyridine | C₅H₅N | 1.7 |
| 44 | Chloroethylene | CH₂CHCl | 3.8 | 92 | Tetrahydrofuran | C₄H₈O | 2.0 |
| 45 | Chloromethane | CH₃Cl | 8.1 | 93 | Tetrahydrofurfuryl | C₅H₁₀O₂ | 1.5 |
| 46 | 2-Chloropropane | CH₃CHCICH₃ | 2.6 | 94 | Triethylamine | (C₂H₅)₃N | 1.2 |
| 47 | Cresol | C₆H₄OH | 1.1 | 95 | Trimethylamine | (CH₃)₃N | 2.0 |
| 48 | Cyclobutane | CH₂CH₂CH₂CH₂ | 1.8 | 96 | Trioxane | (CH₂O)₃ | 3.0 |
Send Message
Just drop us a line, call, or fill out the form. Our team will provide you with transparent pricing, detailed technical data sheets，very feasible solution, and genuine after-sales support—no hidden costs, no empty promises.
